60mm Big Character Handheld Inkjet Printer for Pipe and Steel Tube Inkjet Printer
Specification
| Model | ALS-16 |
| Print head | 16 dots |
| Print height | 30-60mm |
| Software function | Real-time date and clock, Printing batch, Recording |
| Print lines | 1-2 lines |
| Print dot matrix | 16*10, 14*10, 12*8, 9*6, 7*5 |
| Processor | Android 4 Core processor |
| Communication Interface | USB, Wireless, Network port |
| Language | Chinese, English, Arabic, Korean, Spanish, French, German etc |
| Print graphics | Printable trademark graphics, symbols, etc |
| Date code | Support for centuries, years, months, days, hours, minutes, seconds |
| Print speed | Wheel control printing speed, pulse control |
| Print distance | 8mm fixed from the surface of the printed object |
| Status display | Preview information when printing |
| Screen display | Show all print parameters, one-click change settings |
| Trigger way | Photoelectric Inductor Trigger |
| Printing control | Encoder control |
| Printing material | Both permeable or non-permeable materials |
| Ink | Water-based ink (permeable surface) or oily ink |
| Ink color | Black, red, blue, yellow, white,green， optional |
| Way of supply ink | Built-in air pump compression |
| Power parameters | Voltage 24V current 1.5A average power consumption less than 30W |
| The appearance of the machine | Injection body, anti-weary and durable |
| Charging time | No more than 5 hours |
| Use environment | Temperature: -20 to 50 degrees, humidity: 30% to 70% |
Customized conveyor
Product introduction:
1. stepless speed regulation and smooth transmission can transmit various products, packaging bags, cartons, plastic bottles, cans, metal parts, lunch boxes and other types of products.
2. The conveying platform is equipped with various types of inkjet printers for inkjet printing. The inkjet printers can be installed on the sliding rail of the conveying platform to cooperate with the inkjet printing of the conveying platform assembly line, or the floor bracket can be installed on the floor bracket to cooperate with inkjet printing of the conveying platform.
3. Support customization. The length, width and material bearing capacity of the conveying table can be customized. Please consult customer service for other specific requirements.
4. The design of conveyor belt adjusting lever adjusts the product transmission position according to the position and height of product adjusting baffle.
5. Thick conveyor belt, 2MM thick conveyor belt with high quality materials, strong wear resistance and adjustable elasticity.
Customized Paging Machine
Product introduction:
Multi-size can be adapted to all kinds of products, professional matching height, width, thickness, automatic paging device stable and efficient operation, high fault tolerance rate.
Support non-standard customized pagination machine, the size and function of pagination machine can be customized according to product requirements.
Wide paging range, suitable for automatic paging of plastic bags, paper bags, labels, IC cards, etc. Soft, hard, thin and thick can be divided, and combined with inkjet printer for inkjet printing.
With small character inkjet printer, it is suitable for high-yield and large-scale inkjet printing, self-lifting of energy-saving consumables and high adhesion.
With the laser machine, the marking is permanent and clear, the laser has a long service life, can work continuously for a long time, has high efficiency, has a long dimension-free period, has no consumables to use, and reduces the use and maintenance cost.
High-speed intelligent large-scale code spraying with code spraying machine saves time and labor and improves productivity.
High-quality motor with adjustable speed, stable operation | no jitter | low noise | even paging | fast heat dissipation | long service life
Product parameters:
1. The conveying speed is 10-50m/min (adjustable speed)
2. The product power is 120W W.
3. The product load is 8KG
4. Power supply voltage AC220V/50HZ
5. Product size is 1500*480* 890MM (transmission bandwidth is 250MM).
6. Pageable width is 50-300MM.
7. Pageable thickness is 0.1-5 mm.
Domino Ax Series | Continuous Inkjet Printers (CIJ) Ax150i Technical Specification
Domino Ax150i
Entry-level solution for precise CIJ coding
The Ax150i is a compact continuous inkjet (CIJ) printer for basic coding requirements. It offers precise coding of text, graphics and 2D codes on a wide range of materials such as PET, glass and packaging. Thanks to i-Pulse printhead technology, the Ax150i delivers consistent and high-contrast results at moderate production speeds. With a robust IP55 housing, easy maintenance and user-friendly QuickStep interface, the Ax150i is ideal for small and medium production lines.
Whether you’re just starting out or scaling up your production, the Ax150i provides Domino technology at a surprisingly competitive price.
Benefiting from its compact size and highly-responsive stop-start performance, the Ax150i provides maximum flexibility and reliability to meet your changing coding needs. The Ax150i features the i-Pulse printhead for high-quality and consistent printing and supports a wide range of i-Pulse printing inks. Ink and make-up changes are quick and easy thanks to the intelligent consumable system, while the i-Tech module removes the cost and inconvenience of traditional servicing.
With user simplicity at its core, the Ax150i benefits from the i-Techx electronics platform and innovative QuickStep user interface to provide a fast, easy-to-understand and error-reducing experience to the operator. The latest entry-level CIJ printer from Domino, the Ax150i builds on Domino’s strong reputation for high-reliability, ease of use and low cost of ownership industrial printers. The Ax150i is the ideal choice if you want to save money while enjoying flexibility, reliability, and simplicity in batch coding and variable data printing.
The Domino Ax-Series Ax150i is the latest CIJ entry-level printer that replaces a range of i-Tech A-Series products. The Domino A120 and A100+ reputations were built on ease of use, low cost of ownership and low running costs. The Ax150i also replaces the A220. It has the ability to print up to five lines of code and is an ideal choice if you want to save money at the same time as enjoying flexibility, reliability, and simplicity.
| Brand |
Domino
|
| Model Name/Number |
Ax 150i
|
| Print Speed |
9 drop quality at 7 drop speeds
|
| Country of Origin |
Made in UK
|
| Service model |
Service free ITM system
|
| Max lines of print* |
5
|
| Print height* (mm) |
Upto 20mm
|
| Minimum Order Quantity |
1 Unit
|
Feature comparison of the Domino Ax series continuous inkjet printers
Benefiting from its compact size and highly-responsive stop-start performance, the Ax150i provides maximum flexibility and reliability to meet your changing coding needs. The Ax150i features the i-Pulse printhead for high-quality and consistent printing and supports a wide range of i-Pulse printing inks. Ink and make-up changes are quick and easy thanks to the intelligent consumable system, while the i-Tech module removes the cost and inconvenience of traditional servicing.
With user simplicity at its core, the Ax150i benefits from the i-Techx electronics platform and innovative QuickStep user interface to provide a fast, easy-to-understand and error-reducing experience to the operator. The latest entry-level CIJ printer from Domino, the Ax150i builds on Domino’s strong reputation for high-reliability, ease of use and low cost of ownership industrial printers. The Ax150i is the ideal choice if you want to save money while enjoying flexibility, reliability, and simplicity in batch coding and variable data printing.
The Domino Ax-Series Ax150i is the latest CIJ entry-level printer that replaces a range of i-Tech A-Series products. The Domino A120 and A100+ reputations were built on ease of use, low cost of ownership and low running costs. The Ax150i also replaces the A220. It has the ability to print up to five lines of code and is an ideal choice if you want to save money at the same time as enjoying flexibility, reliability, and simplicity.
| Brand |
Domino
|
| Model Name/Number |
Ax 150i
|
| Print Speed |
9 drop quality at 7 drop speeds
|
| Country of Origin |
Made in UK
|
| Service model |
Service free ITM system
|
| Max lines of print* |
5
|
| Print height* (mm) |
Upto 20mm
|
| Minimum Order Quantity |
1 Unit
|
Feature comparison of the Domino Ax series continuous inkjet printers
| Feature | Ax150i | Ax350i | Ax550i |
| Field of application | Simple coding tasks | Complex coding, high speeds | Harsh environments, demanding applications |
| Print speed | Up to 5.1 m/s | Up to 7.1 m/s | Up to 7.1 m/s |
| Printhead options | Straight | Straight, H90, RS and Duo | Straight, H90, RS and Duo |
| Protection class (housing) | IP55 | IP55 (optional IP66) | IP66 |
| Material | Stainless steel 304 | Stainless steel 304 | Stainless steel 316 (seawater resistant) |
| Compatibility | Basic industry protocols | Industry 4.0-compatible | Industry 4.0-compatible |
| Areas of application | Basic applications in food and beverages | Versatile coding in the pharmaceutical, food and industrial sectors | Hard environments in food and beverages |
| User interface | QuickStep 3 with 7-inch touchscreen | QuickStep 3 with 7- or 10.4-inch touchscreen | QuickStep 3 with 7- or 10.4-inch touchscreen |
| Robustness | Basic robustness | Optional IP66 for more demanding conditions | Maximum protection against water and dust |
| Ink options | Standard i-Pulse inks | Advanced i-Pulse inks for MRC and colors | Advanced i-Pulse inks for demanding environments |
Domino Ax Series | Continuous Inkjet Printers (CIJ) Ax350i Technical Specification
The highly adaptable AX350i Continuous Inkjet Printer (CIJ) has an expansive scope of drop sizes, ink types, and configurations that all fit into a stainless steel cabinet. The i-Pulse printheads make printing codes and text on circuit boards, cables, drink cans, and food storage containers a breeze.
- 54 ink options
- Moveable 7 or 10.4-inch screens
- Has 4 i-Pulse printhead variants
The Domino Ax series sets new standards for continuous inkjet (CIJ) printers with the latest i-Pulse printhead technology. It offers speed, precision and versatility for high-quality, permanent coding on a wide range of materials. With a robust design and Industry 4.0 compatibility, the Ax printers are ideal for demanding production environments in the food, beverage, pharmaceutical and industrial sectors.
- High-precision coding: i-Pulse print head technology for sharp and durable codes.
- Versatile applications: Suitable for a wide range of materials and industries.
- Robust and reliable: IP66 options for demanding production environments.
- Industry 4.0-compatible: connection to Domino Cloud for remote monitoring and diagnostics.
Feature comparison of the Domino Ax series continuous inkjet printers
| Feature | Ax150i | Ax350i | Ax550i |
| Field of application | Simple coding tasks | Complex coding, high speeds | Harsh environments, demanding applications |
| Print speed | Up to 5.1 m/s | Up to 7.1 m/s | Up to 7.1 m/s |
| Printhead options | Straight | Straight, H90, RS and Duo | Straight, H90, RS and Duo |
| Protection class (housing) | IP55 | IP55 (optional IP66) | IP66 |
| Material | Stainless steel 304 | Stainless steel 304 | Stainless steel 316 (seawater resistant) |
| Compatibility | Basic industry protocols | Industry 4.0-compatible | Industry 4.0-compatible |
| Areas of application | Basic applications in food and beverages | Versatile coding in the pharmaceutical, food and industrial sectors | Hard environments in food and beverages |
| User interface | QuickStep 3 with 7-inch touchscreen | QuickStep 3 with 7- or 10.4-inch touchscreen | QuickStep 3 with 7- or 10.4-inch touchscreen |
| Robustness | Basic robustness | Optional IP66 for more demanding conditions | Maximum protection against water and dust |
| Ink options | Standard i-Pulse inks | Advanced i-Pulse inks for MRC and colors | Advanced i-Pulse inks for demanding environments |
Domino Ax Series | Continuous Inkjet Printers (CIJ) Ax550i Technical Specification
Domino Ax550i
High-performance CIJ printers for demanding environments
The Ax550i continuous inkjet (CIJ) built with marine-grade stainless steel was built to withstand even the toughest settings. The highly pigmented inks can print crisp text, graphics, and barcodes on various challenging surfaces in the food and beverage industry.
- Over 50 ink alternatives
- 7 or 10.4-inch detachable screen with mounting options
- Has 4 i-Pulse printhead variants
The Ax550i has been specially developed for harsh production environments and is equipped with a housing made of seawater-resistant grade 316 stainless steel. With IP66 protection against dust, water and chemicals and a stackable design, the Ax550i is suitable for demanding applications in the food and beverage industry. The i-Pulse printhead technology and high-performance inks guarantee precise coding, even in high-speed production. Industry 4.0 compatibility and remote monitoring via the Domino Cloud make the Ax550i the ideal solution for maximum productivity.
| Feature | Ax150i | Ax350i | Ax550i |
| Field of application | Simple coding tasks | Complex coding, high speeds | Harsh environments, demanding applications |
| Print speed | Up to 5.1 m/s | Up to 7.1 m/s | Up to 7.1 m/s |
| Printhead options | Straight | Straight, H90, RS and Duo | Straight, H90, RS and Duo |
| Protection class (housing) | IP55 | IP55 (optional IP66) | IP66 |
| Material | Stainless steel 304 | Stainless steel 304 | Stainless steel 316 (seawater resistant) |
| Compatibility | Basic industry protocols | Industry 4.0-compatible | Industry 4.0-compatible |
| Areas of application | Basic applications in food and beverages | Versatile coding in the pharmaceutical, food and industrial sectors | Hard environments in food and beverages |
| User interface | QuickStep 3 with 7-inch touchscreen | QuickStep 3 with 7- or 10.4-inch touchscreen | QuickStep 3 with 7- or 10.4-inch touchscreen |
| Robustness | Basic robustness | Optional IP66 for more demanding conditions | Maximum protection against water and dust |
| Ink options | Standard i-Pulse inks | Advanced i-Pulse inks for MRC and colors | Advanced i-Pulse inks for demanding environments
|
How continuous inkjet technology works
Continuous inkjet printer technology (CIJ) enables contactless and precise coding on moving substrates. The print head remains permanently installed while the substrate – for example packaging, bottles or components – is moved past it. A continuous stream of ink is generated by a high-pressure nozzle and divided into individual droplets using electrical pulses. These droplets are specifically deflected by high-voltage electrodes so that they hit the substrate precisely.
Unused drops are collected in a collection system and recycled, making the technology particularly efficient. CIJ is suitable for high production speeds and is extremely versatile, as it can produce razor-sharp codes on a wide variety of materials and shapes – from flat surfaces to uneven products. This flexibility makes CIJ technology a proven solution in industrial marking.
Domino Printer Spares Parts
China Domino Spare Parts catalog of Domino Compatible Pg0409 Module for 320I Series Continuous Inkjet Printer Whatsapp：+8619303036632
Domino Printer Spares Parts
China Domino Spare Parts catalog of Domino Compatible Pg0409 Module for 320I Series Continuous Inkjet Printer Whatsapp：+8619303036632
Fly CO2 Laser Marking Machine 30W/45W/60W
Why Choose Fly CO2 Laser Marking Machine？
- High Efficiency : marking process in automation, support 24 hours continuous work.
- High Performance : compact structure, high speed engraving and marking, permanent marking result.
- Low Use Cost : no consumable materials, no maintenance, energy saving.
- Long Life: adopting well-known brand laser source, life is more than 70000 hours.
- Easy Use : software is easy to learn and operate, the system can automatically encode and print the serial number ,batch number, date and so on.
- Good Design：Modular design, more flexible to install and easy fit your production line, can adapt to industrial environment.
| Category | Details |
|---|---|
| Model | CO2 Laser (30W, 45W, 60W, 100W) |
| Applications | Apparel accessories, pharmaceutical packaging, beverage packaging, gifts, electronic components, leather, architectural ceramics, etc. |
| Compatible Materials | Non-metals, PVC, PE, PC, CPP, PA, PPO extrusion materials, etc.
|
Laser Specifications
| Parameter | Details |
|---|---|
| Laser Output Power | ≥45W |
| Laser Type | CO2 Generator |
| Wavelength | 10.6μm |
| Marking Speed | ≤8000mm/s |
| Cooling System | Ambient air cooling (no compressed air required) |
| Control Board | Industrial-grade integrated motherboard |
| Operating System | Proprietary marking software |
| Data Protection | Prevents data loss during power outages |
| Lens Rotation | 360° adjustable scanning head |
Physical Specifications
| Parameter | Details |
|---|---|
| Protection Rating | IP54 |
| Total Power | 700W |
| Dimensions | 350mm × 750mm × 1500mm |
| Pollution Level | No chemical emissions during marking
|
Optical & Positioning Parameters
| Parameter | Details |
|---|---|
| Marking Area | ≤400×400mm (standard: 110×110mm) |
| Line Width (Min) | 0.01mm |
| Positioning Accuracy | 0.01mm |
| Focusing Method | Red-light positioning |
| Marking Line Type | Dot matrix, vector
|
Software & Compatibility
| Category | Details |
|---|---|
| Supported Fonts | Single-line, double-line, dot-matrix fonts |
| File Formats | PLT vector file input/output |
| Graphic Elements | Points, lines, arcs, text, rectangles, circles |
| Variable Text | Serial numbers, time, date, counters, shifts |
| Barcodes | Code 39, Code 93, Code 128, EAN-13, etc. |
| 2D Codes | QR Code, Data Matrix, etc. |
Interfaces & Power
| Parameter | Details |
|---|---|
| Interface | USB 2.0 |
| Power Supply | AC 220V, 50-60Hz |
